Wireless MIMO LAN systems & IEEE 802.11n applications
Point-to-point (PtP) for backhaul or client premise equipment (CPE)
Supports public safety (4.9 GHz), U-NII-1, 2, 3, and 4 (5.15-5.925 GHz), and up to 6.85GHz for world-wide market
Mobile WiMAX Wireless Internet Provider “cell” sites
High-density deployments requiring frequency reuse to achieve high capacity and data rates
Last-mile connection
|
Antenna Model |
Antenna Size(m) |
Frequency (GHz) |
Gain(dBi) | 3dB BW
(degs) |
XPD (dB) |
VSWR |
F/B radio (dB) |
ISO |
||
| Low | Mid | Top | ||||||||
| CM02U13D | 0.2 | 12.75-13.25 | 26.5 | 26.7 | 26.9 | 7.3 | 30 | 1.3 | 52 | 35 |
| CM02U18D | 0.2 | 17.7-19.7 | 29.5 | 29.9 | 30.3 | 5.1 | 30 | 1.3 | 56 | 35 |
| CM02U23D | 0.2 | 21.2-23.6 | 31.0 | 31.5 | 32.0 | 4.3 | 30 | 1.3 | 57 | 35 |
| CM02U26D | 0.2 | 24.2-26.5 | 32.2 | 32.6 | 33.0 | 3.8 | 30 | 1.3 | 58 | 35 |
| CM02U28D | 0.2 | 27.5-29.5 | 33.3 | 33.6 | 33.9 | 3.4 | 30 | 1.3 | 59 | 35 |
| CM02U32D | 0.2 | 31.8-33.4 | 34.6 | 34.8 | 35.0 | 3.0 | 30 | 1.3 | 60 | 35 |
| CM02U38D | 0.2 | 37.0-40.0 | 35.9 | 36.2 | 36.5 | 2.5 | 30 | 1.3 | 61 | 35 |
