High-performance gain and patterns that are stable over a wide bandwidth
Interference mitigation with highly suppressed side-lobes and superior front-to-back that allows channel reuse
Over 25 dB cross polarization discrimination and port isolation for optimal MIMO performance
Ideal for high-density AP deployments with radio co-location due to compact size and highly focused radiation
Improved coverage near and far from the tower with equal elevation and azimuth beamwidths
Quick-connect waveguide allows polarization to be adjusted and quick change of adapters without tools
Direct Connect radio-specific and dual polarized N-type connector adapters available
Fine azimuth- and elevation- tilt markings to simplify alignment
Mountable on left or right side of the pole without flipping upside down
| Antenna Model |
Antenna Size(m) |
Frequency (GHz) |
Gain(dBi) | 3dB BW
(degs) |
XPD (dB) |
VSWR |
F/B radio (dB) |
ISO |
||
| Low | Mid | Top | ||||||||
| CM18U6WD | 1.8 | 5.925-7.125 | 38.4 | 39.4 | 39.8 | 1.8 | 30 | 1.3 | 65 | 35 |
| CM18U7WD | 1.8 | 7.125-8.5 | 40.0 | 40.8 | 41.5 | 1.5 | 30 | 1.3 | 66 | 35 |
| CM18U10WD | 1.8 | 10.125-11.7 | 43.0 | 43.7 | 44.3 | 1.1 | 30 | 1.3 | 71 | 35 |
| CM18U13D | 1.8 | 12.75-13.25 | 45.0 | 45.2 | 45.3 | 0.9 | 30 | 1.3 | 70 | 35 |
| CM18U15D | 1.8 | 14.4-15.35 | 46.1 | 46.3 | 46.6 | 0.8 | 30 | 1.3 | 71 | 35 |
| CM18U18D | 1.8 | 17.7-19.7 | 47.9 | 48.3 | 48.8 | 0.6 | 30 | 1.3 | 73 | 35 |
| CM18U23D | 1.8 | 21.2-23.6 | 49.4 | 49.9 | 50.4 | 0.5 | 30 | 1.3 | 75 | 35 |
