4G Indoor CPE ZLT S10
- ZX297520V3E/ZTE
- LTE CAT4150 Mbps(DL)/50 Mbps(UL)
- Multi NR/LTE Bands
- 802.11 b/g/n/ac
- VoNR/VoLTE/VoIP(In Roadmap)
Product Specification
ZLT S10 is a high-performance wireless communication product developed by Hongkong Broadvision Technology Co., Ltd based on 4G network requirements. It is mainly used for data transmission services, equipment monitoring, wireless routing and other functions. ZLT S10 adopts high-performance processor, which can process protocol and large amount of data at high speed. It can be used with a variety of 4G CAT4 module, providing 802.11b/g/n Wi-Fi access.
Product Specification
Hardware Specifications
| Spec | Description |
| Chipset | ZX297520V3E/ZTE |
| LTE standard | LTE CAT4
150 Mbps(DL)/50 Mbps(UL) |
| Memory | ROM: 128MB |
| RAM: 64MB | |
| Interfaces | LAN RJ45 Port (FE) * 1;
DC Socket; Battery Socket (Optional); SMA Interface * 2; SIM Slot * 1; USB Socket (For Manufacture); |
| Indicators | 1. Power/Battery
2. Wi-Fi Switch 3. LTE Network 4.Signal Strength |
| Buttons | POWER On/Off Button
WPS Button RESET Button Wi-Fi Button |
| SIM | Micro SIM(3FF)
Support 1.8V & 3.3V |
| Power Consumption | < 6W (Without Battery) < 12W (With Battery) |
| Charger | AC: 100V~240V
DC: 12V/1A 12V/0.5A (If no need battery) |
| Battery
(Optional) |
Rechargeable lithium battery |
| Capacity: 7.4V/2000mAh | |
| Maximum working hours:
2(depending on the network) |
|
| Maximum standby hours:
8 (depending on the network) |
|
| Dimensions | 130x120x52(mm) |
| Weight | 180g (Without Battery) |
Environment Specifications
Firewall Features
Topology
Software Specifications
WIFI Features
Device Management
RF Specifications
Datasheet
