BMS516CE Multiswitch

  • Very low tap loss
  • 4 satellite IF 1 terrestrial TV inputs to 16 outputs for satellite receivers
  • Allow use of 1 Quatro or up to 2 Dual or Twin LNBs
  • Single coaxial cable conveys both satellite and terrestrial signal
  • External Switching Power Supply can set up the operational power of LNB
  • Circuit design for signal amplifier function

Product Specification

4 satellite IF 1 terrestrial TV inputs to 16 outputs for satellite receivers
Allow use of 1 Quatro or up to 2 Dual or Twin LNBs.
Single coaxial cable conveys both satellite and terrestrial signal.
External Switching Power Supply can set up the operational power of LNB.
Very low tap loss
Circuit design for signal amplifier function.

Product Specification

ITEM TYP REMARK
   Frequency response 47-2150MHz
   Inputs 4SAT+1 Terr F connectors
   outputs 4SAT+1 Terr F connectors
   Subscribers 16 TAP F connectors
   Tap Loss   Terr 47-862MHz 2 dB
  Sat 950-2150MHz 2 dB
   Trunk Loss   Terr 47-862MHz 3 dB
  Sat 950-2150MHz 5.5 dB
   Return Loss   Terr in 47-862MHz 11dB
  Sat in 950-2150MHz 11dB
  Terr out 47-862MHz ( Tap ) 8 dB
  Sat out 950-2150MHz ( Tap ) 8 dB
   Isolation OUT-OUT  Terr 47-862MHz 25dB
 Sat 950-2150MHz 30dB
H/V  Sat 950-2150MHz 26dB
   Rejection 26dB
   Flatness ±2dB
   Output level Sat. ( IMD3-35dB) 98 dBuV
   Output level Terr. ( IMD3-35dB) 92 dBuV
  Switching voltage V:10~14.5V  H:15.5~20V
  Switching commands 13V,18V,13V/22KHz,18V/22KHz
